Brother MFC-8370DN Service Manual

App. 1-54
Confidential
<WSW57> (Function setting 22)
<WSW58> (Function setting 23)
Selector No. Function Setting and Specifications
1
I
3
Caller ID judgment voltage
(to be distinguished from rings)
(Not used.)
4
I
6
Caller ID judgment voltage
(to be distinguished from
reverse polarity voltages)
(Not used.)
7 Not used.
8
Base unit [Start] button after
cordless handset dialing
(Not used.)
Selector No. Function Setting and Specifications
1
I
3
Prevention of line interrupt
during ICM recording (ratio of
guard tone response time to call
end tone ON time)
(Not used.)
4
5
Not used.
6
Extension of the “No. of CNG
cycles to be detected” (which
allows two cycles to be added to
the cycles specified by selectors
6 and 7 on WSW26 and
selectors 4 and 5 on WSW34)
0: No
1: +2 cycles
7
8
No. of busy tone detection
cycles
No. 7 8
0 0: -1 cycle
0 1: +0 cycles (default)
1 0: +1 cycle
1 1: +2 cycles

Brother MFC-8370DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Input color depth	48 bit
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Display	LCD
Product color	Grey, White
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Card reader integrated	-
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	Scan
Power consumption (standby)	85 W
Power consumption (average operating)	680 W
Package weight	21100 g
Digital sender	No
Maximum duty cycle	- pages per month

Weight and Dimensions

Depth	443 mm
Width	390 mm
Height	442 mm
