2-14
Confidential
(4) The switch back roller ASSY is turned counter again, and the document is drawn
again. The document is passed through the paper feed rollers 1, 2 and 3, and
ejected to the document cover by the eject roller.
Fig. 2-15
Switch back roller ASSY
Paper feed roller 2
Paper feed roller 3
Eject roller
