Brother MFC-J6730DW - Disassembly Procedure; Preparation

3-39
Confidential
(14)Remove the two screws (TAPTITE BIND B M4x12) from the Main body.
Fig. 3-16
(15)Lift and remove the Document scanner unit from the Main body.
Fig. 3-17
TAPTITE BIND B M4x12
Main body
Document scanner unit
Main body
