Brother MFC-J6730DW Service Manual

1-14
Confidential
8 SUPPLIES/OPTIONS
9 SERVICE INFORMATION
Model
HL-J6000DW/
J6100DW/
MFC-
J6947DW
HL-
T4000DW/
MFC-
T4500DW
MFC-J3530DW/
J3930DW/
J6530DW/
J6730DW/
J6930DW
MFC-
J6535DW/
J6935DW
MFC-J6545DW/J6945DW
Ink
Cartridge
Yield @
ISO
pattern
(Pages)
Bundled Cartridge
(BK/CL)
2,250/975
N/A
357/357
(Except for China)
2,400/975
(For China)
2,400/975
MFC-J6545DW/J6945DW:
4,000/3,700
(For U.S.A. and Canada)
2,250/975
(Except for U.S.A. and
Canada)
MFC-J6545DW XL:
1 set of 4,000/3,700 and
1 set of 5,100/3,750
Supply High Yield
Cartridge (BK/CL)
3,000/1,500
N/A
550/550
(Except for China)
N/A (For China)
550/550
(For Europe)
N/A (Except
for Europe)
3,000/1,500
Supply Super High
Yield Cartridge
(BK/CL)
6,000/5,000
N/A 3,000/1,500 6,000/5,000
Ink Bottle
Yield @
ISO
pattern
(Pages)
Bundled Bottle
(BK/CL)
N/A
5,850/
4,250
N/A
Supply High Yield
Bottle (BK/CL)
N/A
6,500/
5,000
N/A
Storage Condition of Ink
Cartridge
(Temperature) Normal condition: -20 to 40°C (Humidity) Normal condition: 20 to 80%
* At the temperature of 40 to 50°C and the humidity of 80 to 95%: Up to 5 days
* At the temperature of 40 to 60°C and the humidity of Non control condition: Up to 5 days
Model All models
Monthly Volume Up to 30,000 pages
Machine Life 100,000 pages or 5 years
MTBF (Mean Time Between Failures) 4,000 hours
MTTR (Mean Time To Be Repaired) 30 minutes

Brother MFC-J6730DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	4800 x 1200 DPI
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	22 ppm
Print speed (color, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Scanner type	ADF scanner
Maximum scan area	295 x 429.8 mm
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	- DPI
Optical scanning resolution (black)	600 x 600 ppi
Optical scanning resolution (color)	600 x 300 ppi
Faxing	Color faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax forwarding to	PC
Fax speed dialing (max numbers)	100
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Display	LCD
Control type	Touch
Product color	Black
Market positioning	Home & office
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	501 sheets
Auto document feeder (ADF) input capacity	50 sheets
Envelopes sizes	C5, Com-10, DL, Monarch
Paper tray media types	Glossy paper, Plain paper, Recycled paper
Non-ISO print media sizes	Folio (media size), Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5, B6
Photo paper sizes (imperial)	9x13, 10x15, 13x18 \
Maximum ISO A-series paper size	A4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA2-TKIP
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	128 MB
Standard interfaces	Ethernet, USB 2.0
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.04 W
Power consumption (ready)	6 W
Power consumption (sleep)	1.6 W
Power consumption (copying)	28 W
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista

Weight and Dimensions

Depth	477 mm
Width	575 mm
Height	374 mm
