Brother MFC-J6730DW Service Manual

5-18
Confidential
1.3.8 Updating of Firmware Using a USB flash memory (Maintenance mode 28)
< Function >
This function updates firmware stored in the flash ROM on the main PCB using a USB
flash memory. It enables updating of firmware without connecting the machine to a PC.
TIP: For instructions on how to update firmware when the main PCB has been
replaced or for operations using a PC, refer to Chapter 4, Section 1.3 "Install the
firmware (Maintenance mode 28)."
< Operating Procedure >
(1) Switch your PC ON and insert a USB flash memory.
(2) Create a folder named "BROTHER" in the top layer of the USB flash memory's
directory and copy the firmware file having the extension ".djf" into that folder.
Note: Before copying, check that the firmware file name having the extension ".djf"
matches your machine. The number of files having the extension ".djf" in the
"BROTHER" folder should be 100 or less.
Tip: If a firmware file not matching the machine is used, the firmware cannot be
updated, but note that you can superficially continue the operation until step
(5) below without any error.
(3) Remove the USB flash memory from the PC and insert it into the machine in the
initial stage of the maintenance mode.
(4) On the machine, press the 2 and 8 keys in this order.
The file name "********.djf" appears on the LCD.
(5) Press the
▲ or ▼ key to select the target firmware file.
(6) Press the Mono Start key.
"Program Updating" appears on the LCD.
Note: Never remove the USB flash memory from the machine when updating is in
progress.
(7) Updating will complete in a few minutes, and the machine automatically restarts
and returns to the standby state.
Remove the USB flash memory from the machine and store it in a safe place.
Note: If any of the error messages listed below appears, press the X key, and the
machine returns to the initial stage of the maintenance mode.
Error Message Cause
Card is used
The USB flash memory is being used by another
operation.
Insert Card
No USB flash memory is inserted.
No file
No file with the djf extension. / No "BROTHER" folder
exists.
Card Error
USB flash memory defective

Brother MFC-J6730DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	4800 x 1200 DPI
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	22 ppm
Print speed (color, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Scanner type	ADF scanner
Maximum scan area	295 x 429.8 mm
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	- DPI
Optical scanning resolution (black)	600 x 600 ppi
Optical scanning resolution (color)	600 x 300 ppi
Faxing	Color faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax forwarding to	PC
Fax speed dialing (max numbers)	100
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Display	LCD
Control type	Touch
Product color	Black
Market positioning	Home & office
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	501 sheets
Auto document feeder (ADF) input capacity	50 sheets
Envelopes sizes	C5, Com-10, DL, Monarch
Paper tray media types	Glossy paper, Plain paper, Recycled paper
Non-ISO print media sizes	Folio (media size), Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5, B6
Photo paper sizes (imperial)	9x13, 10x15, 13x18 \
Maximum ISO A-series paper size	A4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA2-TKIP
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	128 MB
Standard interfaces	Ethernet, USB 2.0
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.04 W
Power consumption (ready)	6 W
Power consumption (sleep)	1.6 W
Power consumption (copying)	28 W
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista

Weight and Dimensions

Depth	477 mm
Width	575 mm
Height	374 mm
