1.2 List of Maintenance-mode Functions
Shaded maintenance mode functions are available to end users.
* Exclusive to the end user-accessible maintenance mode.
Maintenance
Mode
Function
Reference Section
(Page)
01 EEPROM Parameter Initialization
1.3.1 (5-5)
02
Creating of Head Calibration Data and Writing it into Flash ROM
1.3.2 (5-6)
08 ADF Performance Test 1.3.3 (5-11)
09 Printout of Test Pattern 1.3.4 (5-12)
10 Worker Switch (WSW) Setting 1.3.5 (5-13)
11 Printout of Worker Switch (WSW) Data 1.3.5 (5-13)
12 Operational Check of LCD 1.3.6 (5-15)
13 Operational Check of Keys on Control Panel 1.3.7 (5-17)
28 Updating of Firmware Using a USB flash memory 1.3.8 (5-18)
32 Sensor Operational Check 1.3.9 (5-19)
37* Printout of Dial Log 1.3.10 (5-21)
45
PCL/PS function setting
(MFC-J6935DW/J6945DW/J6947DW, HL-J6000DW/J6100DW only)
1.3.11 (5-22)
46 Backup of Machine Information 1.3.12 (5-23)
53 Transfer of Received FAX Data and/or Equipment's Log 1.3.13 (5-25)
54 Fine Adjustment of Scanning Position 1.3.14 (5-27)
55 Acquisition of White/Black Level Data 1.3.15 (5-28)
56
Periodic Purge Time Setting (Ink tank model/Simple Ink cartridge
model only)
1.3.16 (5-28)
57 Cartridge IC Communication Check 1.3.17 (5-29)
58 Updating of Paper Feeding Correction Values 1.3.18 (5-30)
59 Checking of CIS Travel and Setting of CIS Type 1.3.19 (5-34)
61 Printout of PRN/JPEG Files in USB Flash Memory 1.3.20 (5-35)
63 Move of the Head/Carriage Unit to the Adjustment Position 1.3.21 (5-36)
65
Adjustment of Software Correction for Inclination/Corrugation/Ruled
Lines
1.3.22 (5-37)
66 Adjustment of Margins in Borderless Printing 1.3.23 (5-39)
68
Updating of Head Property Information and Backup/Restoration of
Head Calibration Data
1.3.24 (5-41)
69 Traveling Speed Check of Head/Carriage Unit 1.3.25 (5-43)
74 Customizing Destinations 1.3.26 (5-43)
75 Move of the Head/Carriage Unit to the Center 1.3.27 (5-46)
76 Purge Operation 1.3.28 (5-47)
77 Print of the Maintenance Information 1.3.29 (5-51)
78 Adjustment of Touch Panel 1.3.30 (5-58)
80 Display of the Equipment's Log 1.3.31 (5-59)
82 Equipment Error Code Indication 1.3.32 (5-72)
87 Output of Transmission Log to the Telephone Line 1.3.33 (5-72)
88 Assurance Mode Switch Setting (AMS) 1.3.34 (5-73)
89
Printout of Block Pattern (Ink tank model/Simple Ink cartridge model
only)
1.3.35 (5-82)
91 EEPROM Parameter Initialization 1.3.1 (5-5)
99 Exit from the Maintenance Mode
