5-35
Confidential
1.3.20 Printout of PRN/JPEG Files in USB Flash Memory (Maintenance mode 61)
< Function >
This procedure prints PRN files and JPEG files stored in a USB flash memory.
The following four print modes are available.
- Printing the specified file once
- Printing the specified file repeatedly
- Printing all PRN/JPEG files once
- Printing all PRN/JPEG files repeatedly
File requirements
File with PRN or JPG (or prn or jpg) extension in root folder or "BROTHER" folder.
Note: Un-displayable characters in filenames will be replaced with different characters.
Only the first 16 characters of filenames are displayed.
< Operating Procedure >
Note: Before carrying out maintenance mode 61, update the firmware to the latest
version.
(1) Insert a USB flash memory.
(2) Press the 6 and 1 keys in this order in the initial stage of the maintenance mode.
The "MAINTENANCE 61" appears on the LCD.
(3) To print a PRN file(s), press the # key; to print a JPEG file(s), press the * key.
Files of the selected type appear on the LCD.
(4) To print the specified file once, select the target file with the
â–² / â–¼ keys and press
the 4 key.
To print the specified file repeatedly, select the target file with the
â–² / â–¼ keys and
press the 6 key.
To print all files of the selected type once, press the 7 key.
To print all files of the selected type repeatedly, press the 9 key.
(5) The "1.A4 2.LETTER" appears on the LCD.
(6) Pressing the 1 key or the 2 key, in accordance with the size of the recording paper,
starts printing. Upon completion of printing, the machine returns to the initial stage
of the maintenance mode. Pressing the X key during repeated printing returns the
machine to the state showing the "MAINTENANCE 61" on the LCD.
Notes: - This function is not available when Error Code A*** or B*** occurs.
- When recording paper runs out during printing, the maintenance mode
goes back to the initial state, therefore, be sure to load recording paper in
the paper tray before executing printing.
