Brother MFC-J6730DW Service Manual

Confidential
2-10
3 ERROR INDICATION
To help the user or the service personnel promptly locate the cause of a problem (if
any), the machine incorporates the self-diagnostic functions which display error
messages for equipment errors.
3.1 Error Code
Error
Code
Contents
Refer to
page:
0D00 Paper jam during duplex-printing
- The recording papers are fed in reverse on the platen when switchback
drive is started, triggering switchback sensor as paper feeding condition.
2-25
0E00 Defective during duplex-printing
- Switchback sensor detects paper feed condition at out of specified
timing during switchback.
2-25
1300 Defective during duplex-printing
- Registration sensor detects paper feed condition at out of specified timing
during switchback.
2-26
1500 Paper jam during duplex ejecting
- Recording paper is not able to be ejected since it is longer than 840 mm
when ejecting the paper. (The registration sensor stays in the paper
feeding condition during ejecting.)
2-26
1700 Recording paper size error (duplex-printing/duplex-copying)
- Paper width is narrower than 95.5 mm (detection by paper width
sensor)
- Paper length is longer than 461.8 mm (detection by registration sensor)
- Paper length is shorter than 143.5 mm (detection by registration sensor)
2-27
1800 Paper jam during duplex-printing
- Registration sensor does not detect paper feed within specified pulse
numbers in the second side paper re-feed.
2-27
2000 Cannot identify a black ink cartridge.
- The ink cartridge detection sensor and the ink remaining sensor are
detecting.
2-28
2001 Cannot identify a yellow ink cartridge.
- The ink cartridge detection sensor and the ink remaining sensor are
detecting.
2-28
2002 Cannot identify a cyan ink cartridge.
- The ink cartridge detection sensor and the ink remaining sensor are
detecting.
2-28
2003 Cannot identify a magenta ink cartridge.
- The ink cartridge detection sensor and the ink remaining sensor are
detecting.
2-28
2100 Black ink cartridge side IC chip relation defective
- Detecting setting wrong color
2-28
2101 Yellow ink cartridge side IC chip relation defective
- Detecting setting wrong color
2-28
2102 Cyan ink cartridge side IC chip relation defective
- Detecting setting wrong color
2-28
2103 Magenta ink cartridge side IC chip relation defective
- Detecting setting wrong color
2-28

Brother MFC-J6730DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	4800 x 1200 DPI
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	22 ppm
Print speed (color, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Scanner type	ADF scanner
Maximum scan area	295 x 429.8 mm
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	- DPI
Optical scanning resolution (black)	600 x 600 ppi
Optical scanning resolution (color)	600 x 300 ppi
Faxing	Color faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax forwarding to	PC
Fax speed dialing (max numbers)	100
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Display	LCD
Control type	Touch
Product color	Black
Market positioning	Home & office
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	501 sheets
Auto document feeder (ADF) input capacity	50 sheets
Envelopes sizes	C5, Com-10, DL, Monarch
Paper tray media types	Glossy paper, Plain paper, Recycled paper
Non-ISO print media sizes	Folio (media size), Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5, B6
Photo paper sizes (imperial)	9x13, 10x15, 13x18 \
Maximum ISO A-series paper size	A4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA2-TKIP
Ethernet LAN data rates	10, 100 Mbit/s
Internal memory	128 MB
Standard interfaces	Ethernet, USB 2.0
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.04 W
Power consumption (ready)	6 W
Power consumption (sleep)	1.6 W
Power consumption (copying)	28 W
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista

Weight and Dimensions

Depth	477 mm
Width	575 mm
Height	374 mm
