9.29 LCD PCB
(1) Disconnect the three Flat cables from the LCD PCB.
(2) Remove the LCD PCB from the LCD holder.
Fig. 3-72
1
1
1
2
Hook
LCD PCB
Panel PCB flat cable
Touch panel plate FFC
LCD flat cable
Lock
LCD holder
