Brother MFC-J6730DW - Overview of Gears

3-25
Confidential
Disassembly/reassembly time (seconds)
9.32 Wireless
LAN PCB
30/35
9.33 Main PCB
15/15
9.34
Modem PCB
10/10
9.39 Ink
Refill ASSY
20/30
9.43 Switchback
Sensor PCB
25/30
9.47 LT
Frame ASSY
30/45
9.49
Power Supply
PCB ASSY
25/30
9.48 T2
Bank ASSY
25/25
9.50
Switchback Roller
20/25
9.57 Platen/
Paper Ejection
Roller
40/45
9.58 Registration
Sensor PCB
45/65
9.59
Flushing Box
5/10
9.60 Paper Feed
Arm Frame ASSY
5/10
9.61
T1 Bank ASSY
25/35
9.38 CR
Timing Belt
10/15
9.44 CR
Encoer Strip
10/10
9.45 Carriage
Motor
50/60
9.46 Flushing
Base
5/5
9.41 Ink Cartridge
Cover Sensor
10/15
9.40 Ink Absorber
Felt (For Ink
Refill ASSY)
5/5
9.35 Carriage
PCB ASSY
60/70
9.36 Head
Joint Rubber
20/20
9.37
Head/carriage Unit
15/15
9.55
Maintenance Unit
25/40
9.56 Ink Absorber Felt
(For Maintenance Unit)
5/5
