8 DISASSEMBLY FLOW
 Disassembly flowchart
Disassembly/reassembly time (seconds)
9.5
Jam Clear Cover
9.12 ADF Cover
5/5
9.23 Ink
Cartridge Cover
5/10
9.42 Ink
Absorber Box
10/15
9.62 T1 Base
Pad/T2 Base Pad
9.9
ADF Front Cover
15/20
9.10
ADF Side Cover
5/5
9.6 Document
scanner unit
9.20 First Side
CIS Unit/First Side
CIS Flat Cable
65/85
9.8 ADF Unit
10/10
9.21 Document
Cover Sensor
10/20
9.19 Second
Side CIS Flat
Cable/Second
Side CIS Unit
50/80
9.25 Control
Panel ASSY
40/50
9.26 Panel
Flat Cable
30/25
9.27 NFC PCB
5/10
9.28 Panel PCB
5/10
9.29 LCD PCB
10/15
9.30 LCD
10/20
9.31
Touch Panel
10/15
9.14 ADF Separation
Pad Holder ASSY
15/15
9.51 PF
Encoder Disk
5/10
9.18 Document
Scanning
Position Sensor
PCB
15/15
9.17 ADF
Document Detection
Sensor/ADF
Document Width
Sensor PCB
5/5
9.16 ADF Hinge
45/55
9.15 ADF
Document Support
15/20
9.13 Document
Separation Roller
ASSY
5/5
9.22 Front
Cover L
5/10
50/75
9.11 ADF
Rear Cover
15/10
30/35
9.4 MP Paper
Detection Sensor PCB
30/25
9.3 MP
Side Cover R
5/5
9.2 MP
Side Cover L
5/5
9.7 Scanner
Side Cover R
10/10
9.6 Scanner
Side Cover L
10/10
9.2 Paper
Support ASSY
5/5
5/5
10/10
9.52 PF Encoder
Sensor PCB
15/25
9.53 Paper
Feed Motor
30/35
9.54 Paper
Feed Roller
10/15
9.24
Upper Cover
