3-41
Confidential
9.7 Document Scanner Side Cover R
(1) Remove the screw (TAPTITE CUP B M3x10) from the Document scanner side
cover R.
(2) Insert a flat screwdriver into the cutout and release the section “A” and section “B”.
(3) Slide the Document scanner side cover R in the direction of the arrow and release
the eight Hooks.
Fig. 3-20
(4) Release the two Hooks and remove the Document scanner side cover R from the
Document scanner unit.
Fig. 3-21
TAPTITE CUP B M3x10
Hooks
Document scanner
side cover R
Cutout
“A”
“B”
Cutout
Cutout
Flat screwdriver
Hooks
Hooks
Hook
Hook
Document scanner side cover R
Hook
Document scanner unit
Hook
