3-62
Confidential
9.23 Ink Cartridge Cover
(1) Open the Ink cartridge cover.
(2) Release the two Pins and remove the Ink cartridge cover from the Main body.
Note: When replacing the Ink cartridge cover, be sure to remove the serial number
label attached inside the old cover and attach it to the new cover.
Fig. 3-56
Ink cartridge cover
Main body
Pins
1
2
