I-1
CHAPTER I SPECIFICATIONS
1.1 MECHANICAL SPECIFICATIONS
1.1.1 External Appearance
Fig. 1.1-1 External Appearance
(1) Dimensions (W x D x H) 154 x 129 x 60 mm
(PT-1100/1130/1170/1180/11Q/ST-1150)
154 x 129 x 64 mm (PT-1250/1160)
(2) Weight
Machine proper only Approx. 400 g
In package
Packaging Weight (g)
Carton with One Unit 670g
Clamshell 650g
Carrying Case 1300g
(including the machine, packing materials and packaged
standard components)
1.1.2 Keyboard
(1) Entry system Rubber 41 key (PT-1100/1130/1170/1180/11Q/ST-1150)
Rubber 40 key and tact switch (PT-1250/1160)
(2) Number of alphanumeric 30
and symbol keys
(3) Number of function keys 11 (PT-1100/1130/1170/1180/11Q/ST-1150)
10 (PT-1250/1160)
(including On/Off key, L/R pointing keys must be counted
as one.)
(4) Key arrangement See Fig. 1.1-2.
