Brother P-Touch PT-1180 Service Manual

III-13
3.2.8 Oscillation Circuit
Fig. 3.2-17 shows the oscillation circuit.
This circuit contains an oscillator and generates an oscillation at 8 MHz which act as the CPU
basic clock. The CPU divides this into half (4 MHz) to synchronize its internal operations.
Fig. 3.2-17 Oscillation Circuit
