306
GEARCASE – STANDARD ROTATION
SHIFTER, BEARING AND SEAL SERVICING
Place the shift lever arms into the recesses of the
shift cradle. Pull shifter dete nt back up to NEU-
TRAL position to ho ld the cradle and sh aft in
place.
Coat thrust bearing and thrust washer with Needle
Bearing grease. Place the be aring on the b ack of
the gear. Set the washer on top of the thrust bear-
ing. Insert the g ear, bearing, and wash er into the
bearing housing.
Bearing and washer must be
installed in the correct order.
Align holes in the clutch dog with slot in the pro-
peller shaft. Install the clutch dog on the shaft with
“PROP END” facing rear of the shaft.
The clutch dog is not symmetrical.
If inst alled ba ckward, it will no t fully enga ge
and will immediately damage itself and the
gears.
Slide the prop eller shaft onto the shift shaft, align
the hole in the shaft with t he ho le in th e clutch
dog, inst all the pin and th en, a new cl utch d og
retaining spring. Place three coils over each end
of the pin, MAKING SURE NONE OF THE COILS
OVERLAP OR ARE LOOSE.
001219
1. Thrust bearing
2. Thrust washer
006905
1. “PROP END” 006906
1. Retaining spring 006907
