358
TRIM AND TILT
TRIM AND TILT SERVICE
removed later for the Pressure Leak down Test
on p. 341.
Install the re servoir f ilter screen in the cylin der
body. Make sure that the screen is seate d. Use a
6 mm Allen wrench to install the plug. Tighten the
plug securely.
Lubricate and place a new rese rvoir O-ring in the
cylinder body.
Attach the reservoir to the cylinder body with three
Pozidriv screws. Tighten the screws to a torque of
35 to 52 in. lbs. (4.0 to 5.9 N·m).
Trim Rod Installation
Lubricate th e trim rod pistons. Place the r od
assemblies in to the bo dy. Push the m in until the
end cap s just clea r the top s o f the cylinders. Fill
the cylinders with Power Trim/Tilt & Steering Fluid.
Failure to fill the cylinders could cause difficulty in
purging air from the unit.
Screw the trim rod end caps into the cylinder body.
Use Trim Cylin der End Cap Remover/In staller,
P/N 436710, o r Universal S panner W rench,
41851
41863
1. O-ring 41865
41866
41867
