7-2
MIDSECTION
TILLER HANDLE
TILLER HANDLE
Removal / Installation
REMOVAL
1. Remove the throttle cable from the carburetor and the
intake manifold.
2. Remove the lead wires / cable binder, then take out the
throttle control cable from the lower cover.
(See page 6-3)
3. Remove the engine stop switch from the tiller handle.
4. Remove the pivot nut and the washer.
5. Remove the pivot bolt.
6. Remove the tiller handle from the steering bracket.
7. Remove the two bushings.
To Next Page
