9-7
WIRE / HOSE ROUTING
CABLE / WIRE ROUTING
CABLE / WIRE ROUTING
NOTE:
• Wind the protector tube on the cable and position the wire
as shown.
• Route the cable and the wire through the upper side of the
tiller handle.
30 mm
Protector tube
