5-2
MANUAL STARTER
REMOVAL
REMOVAL
1. Loosen the lock nuts 1 and remove the NSI cable 2 from
the bracket
3.
2. Remove the NSI cable from the clutch notch plate
4.
3. Remove the fuel tank cap.
4. Detach the cushion plate
5 of the fuel tank.
5. Loosen the lock nuts
6 and remove the NSI cable 2 from
the recoil starter.
6. Remove the three bolts and the recoil starter.
