BRP Johnson 4HP - Shift Rod Assembly; Water Pump and Related Items

8-12
GEARCASE
SHIFT ROD ASSEMBLY
SHIFT ROD ASSEMBLY
• Apply Triple-Guard grease to the shift rod guide, O-rings
and the top of the dust boot.
 Triple-Guard Grease
• Install the shift rod assembly with the stepped section of
the shift cam toward the propeller shaft.
• Apply Nut Lock to the shift rod guide stopper bolt and
tighten the bolt to the specified torque.
 Nut Lock
 Shift rod guide stopper bolt:
8 N·m (0.8 kg-m; 6.0 lb-ft)
WATER PUMP AND RELATED ITEMS
• Install the water pump case while rotating the driveshaft
clockwise in order to flex the impeller vanes in the correct
direction.
• Apply Nut Lock to the water pump case nuts and tighten
the nuts to the specified torque.
 Nut Lock
 Water pump case nut: 8 N·m (0.8 kg-m; 6.0 lb-ft)
