7-8
MIDSECTION
STEERING BRACKET / DRIVESHAFT HOUSING / SWIVEL BRACKET / CLAMP BRACKET
10. Remove the driveshaft housing / steering bracket assem-
bly and the bushings from the swivel / clamp bracket
assembly.
11. Remove the two bolts, the steering bracket and the
bracket cover.
12. Remove the upper mount and the lower mount.
13. Remove the tilt pin.
14. Remove the nut, the washer, the lower rod and the
through bolt.
15. Remove the nut and the washer, then detach the port
clamp bracket.
16. Remove the clamp bracket shaft bolt and the starboard
clamp bracket.
