Magnet Access and Rigging
H157654_9_011 29 / 120
4.3 Transport Dimensions and Weights
4.3.1 Magnet Transport Dimensions
Door Dimensions for Magnet Access
Crate Size (m) Magnet Transport Dimensions (m)
(for transport to the magnet room)
Magnet Type
(MHz/mm)
L W H Width Un-
crated
Height Un-
crated w/o
Pallet Jack*
Height Un-
crated with
Pallet
Jack**
300/54 Ascend ULH 1.14 0.93 1.99 0.80 1.39 1.50
400/54 Ascend 1.14 0.93 1.99 0.80 1.39 1.50
400/54 Ascend ULH 1.14 0.93 1.99 0.80 1.59 1.70
500/54 Ascend 1.14 0.93 1.99 0.80 1.39 1.50
500/54 Ascend ULH 1.15 1.36 2.06 0.95 1.74 1.85
600/54 Ascend 1.14 0.93 1.99 0.80 1.60 1.71
600/54 Ascend ULH 1.51 1.29 2.18 1.10 1.86 1.97
700/54 Ascend 1.14 1.36 2.06 0.95 1.74 1.85
800/54 Ascend 1.51 1.29 2.18 1.10 1.86 1.97
ULH = Ultra Long Hold
* Measured from magnet bottom plate to helium tower - this is the absolute minimum
height!
** The heights listed with pallet jack assume that the floor is level, thus the magnet
needs only to be jacked up approx. 2 cm for transport. If the floor is uneven, the magnet
may need to be jacked up with a pallet jack, which could add as much as 9 cm to the
transport height.
Table4.1: Door Dimensions: Standard Bore 54 mm
