Bruker AVANCE NEO - Magnet Stand Transport Dimensions; Table 4.4: Door Dimensions for Magnet Stand: Standard Bore 54 MM

Magnet Access and Rigging
H157654_9_011 31 / 120
4.3.2 Magnet Stand Transport Dimensions
Door Dimensions for Magnet Stand & Accessories Access
Accessories Crate Size - including stand if
applicable (m)
Magnet Stand L W H
300/54 Ascend ULH F80 570 0.97 0.75 1.20
300/54 Ascend ULH F80 700 0.97 0.75 1.20
400/54 Ascend F80 570 0.97 0.75 1.20
400/54 Ascend F80 700 0.97 0.75 1.20
400/54 Ascend ULH F80 570 0.97 0.75 1.20
400/54 Ascend ULH F80 700 0.97 0.75 1.20
500/54 Ascend F80 570 0.97 0.75 1.20
500/54 Ascend F80 700 0.97 0.75 1.20
500/54 Ascend ULH F95-700 1.32 0.74 1.30
600/54 Ascend F80 700 0.97 0.75 1.20
600/54 Ascend F80 770 0.97 0.75 1.20
600/54 Ascend ULH F110 800 1.32 0.77 1.32
600/54 Ascend ULH F110 950 1.32 0.77 1.32
700/54 Ascend F95 700 1.32 0.74 1.31
700/54 Ascend F95 880 1.32 0.74 1.31
800/54 Ascend F110 800 1.32 0.77 1.31
800/54 Ascend F110 950 1.32 0.77 1.31
ULH = Ultra Long Hold. Pallet is integrated in crate. Add 2-10 cm for pallet jack depend-
ing on floor quality. Allow at least 1 cm clearance on the sides and above the crate.
Table4.4: Door Dimensions for Magnet Stand: Standard Bore 54 mm
