Ceiling Height Requirements
H157654_9_011 41 / 120
Ceiling Height Requirements
The number in the following tables corresponds to a standard magnet configuration using a
minimum height stand. The ceiling height can increase up to 250 mm based on the model of
the magnet and stand.
Magnet Type Special LHE Transfer Line
for Reduced Ceiling
Height (m)
Standard LHE Transfer
Line (m)
300/54 Ascend ULH 2.52 2.81
400/54 Ascend 2.52 2.81
400/54 Ascend ULH 2.72 3.01
500/54 Ascend 2.52 2.80
500/54 Ascend ULH 3.00 3.28
600/54 Ascend 2.85 3.14
600/54 Ascend ULH 3.23 3.50
700/54 Ascend 3.00 3.28
800/54 Ascend 3.25 3.53
ULH = Ultra Long Hold.
Table5.2: Minimum Ceiling Height Requirements: Standard Bore 54 mm
Magnet Type Special LHE Transfer Line
for Reduced Ceiling
Height (m)
Standard LHE Transfer
Line (m)
300/89 Ascend 2.86 3.16
400/89 Ascend 2.91 3.20
500/89 Ascend 3.10 3.39
600/89 Ascend 3.25 3.53
700/89 Ascend 3.40 3.68
Table5.3: Minimum Ceiling Height Requirements: Wide Bore 89 mm
Magnet Type Special LHE Transfer Line
for Reduced Ceiling
Height (m)
Standard LHE Transfer
Line (m)
200/154 Ascend 3.20 3.48
300/154 Ascend 3.20 3.48
Table5.4: Minimum Ceiling Height Requirements: Super Wide Bore 154 mm
Ceiling Height for Installation
Bruker is using different tools to lift the magnet up to the magnet stand. A-Frames and tripods
are typically height adjustable. Worst case a magnet system can be lifted from the magnet
bottom plate or assembled nearby.
