Floor Plan
H157654_9_011 87 / 120
9.12 Layout Examples
The following layout examples of some NMR systems include the equipment and utilities. A
description of each of the NMR system components is presented in the chapter System Com-
ponents [}21], while the details regarding the utility requirements are presented in the chap-
ter Utility Requirements [}61].
If a CryoProbe System is planned, be sure to refer to CryoProbe and Other Accessories
[}91] for specific information on CryoProbe site requirements.
Figure9.4: Ascend 400 Layout Example
