Bruker AVANCE NEO - Figure 9.2: Magnet Dimensions

Floor Plan
H157654_9_011 81 / 120
Magnet Dimensions and Mass
The values in the following table correspond to the following figure:
Figure9.2: Magnet Dimensions
A. Maximum magnet diameter
B. Magnet height from the floor, including stand.
C. Overall footprint diameter
Refer to the Magnet Dimensions and Total Weights table for the values of A, B, and C.
