Bruker AVANCE NEO - Figure 9.5: Top View of the Ascend 400 Magnet

Floor Plan
88 / 120 H157654_9_011
Figure9.5: Top View of the Ascend 400 Magnet
1 Temperature Control Unit BCU I 4 Operator Desk
2 Magnet System 5 AVANCE NEO Console
3 0.5 mT (5 Gauss) Line
