Bruker AVANCE NEO - Figure 9.7: Top View of the Ascend 800 Magnet

Floor Plan
90 / 120 H157654_9_011
Figure9.7: Top View of the Ascend 800 Magnet
1 AVANCE NEO Console 7 He Gas Cylinder 6.0 for CryoPlatform
2 Temperature Control Unit BCU I 8 Damping Post for CryoProbe Trans-
fer Line
3 Magnet System 9 CryoPlatform
4 0.5 mT (5 Gauss) Line 10 Preamplifier
5 Sample Changer 11 He Compressor Air Cooled Version
6 Operator’s Desk 12 Outdoor Heat Exchanger Air Cooled
