Bruker AVANCE NEO User Manual

Magnet Access and Rigging
32 / 120 H157654_9_011
Accessories Crate Size - including stand if
applicable (m)
Magnet Stand L W H
300/89 Ascend F80 770 0.97 0.75 1.20
400/89 Ascend F80 770 0.97 0.75 1.20
500/89 Ascend F80 950 0.97 0.75 1.49
600/89 Ascend F95 950 1.32 0.74 1.31
700/89 Ascend F110 950 1.32 0.77 1.31
Pallet is integrated in crate. Add 2-10 cm for pallet jack depending on floor quality. Allow
at least 1 cm clearance on the sides and above the crate.
Table4.5: Door Dimensions for Magnet Stand: Wide Bore 89 mm
Accessories Crate Size - including stand if
applicable (m)
Magnet Stand L W H
200/154 Ascend F85 1050 0.79 0.75 1.49
300/154 Ascend F85 1050 0.79 0.75 1.49
Pallet is integrated in crate. Add 2-10 cm for pallet jack depending on floor quality. Allow
at least 1 cm clearance on the sides and above the crate.
Table4.6: Door Dimensions for Magnet Stand: Super Wide Bore 154 mm
4.3.3 Magnet Transport Weights
Magnet Transport Weights
Magnet Type Magnet Weight with
Crate (kg)
Magnet Weight w/o
Crate & Stand (kg)
300/54 Ascend ULH ~415 304
400/54 Ascend ~469 358
400/54 Ascend ULH ~510 378
500/54 Ascend ~560 449
500/54 Ascend ULH ~822 617
600/54 Ascend ~741 609
600/54 Ascend ULH ~1259 963
700/54 Ascend ~1203 998
800/54 Ascend ~2075 1777
The weights of the accessories are approximations. The actual weight may vary depend-
ing on the options and accessories that are ordered.
Table4.7: Magnet Transport Weights: Standard Bore 54 mm
