Ceiling Height Requirements
40 / 120 H157654_9_011
5.2 Minimum Ceiling Height
The minimum ceiling height requirements for operation of each magnet are listed in the fol-
lowing table. Note that the values represent the absolute minimum, an extra 0.3-0.4 m above
minimum requirements will make all procedures safer and more convenient.
Note: The minimum ceiling height requirements for INSTALLATION may be greater than the
values in the table below, depending on the options selected.
Note: When calculating the minimum ceiling height, the height of the transport dewar plus
the long arm of the transfer line must be considered. Refer to the transport dewar supplier for
height specifications.
The following text explains how the ceiling height requirements in the ceiling height require-
ments table were either calculated and/or their meaning. Note that the values were calculated
for the smallest available magnet stand.
Minimum Operational Ceiling
Height – Helium Transfer
Line 29085:
The minimum operational ceiling height using the he-
lium transfer line 29085 is calculated by the height of
the helium port and the length of the short arm of the
helium transfer line.
Minimum Ceiling Height with
Helium Transfer Line 53962:
The ceiling height using the standard helium transfer
line 53962 is calculated by the height of the helium port
and the length of the short arm of the helium transfer
line.
Minimum Ceiling Height for
BST and Adapter WB -> SB:
For the installation the length of the BST is an impor-
tant factor for the ceiling height. For special small ceil-
ing heights, Bruker has a Bruker Sample Transport
(BST) as a 2-piece system available. For all wide bore
systems, the minimum ceiling height is calculated to
the top of the upper part reduction adapter WB -> SB.
