Magnet Access and Rigging
H157654_9_011 35 / 120
4.4 Rigging Equipment
Rigging equipment is not included with the NMR system order. The following rigging equip-
ment will be needed for a typical delivery and installation of an NMR magnet system:
• Pallet Jack and/or Fork Lift: For transporting system magnet and accessories to the lab-
oratory.
• A-Frame or Lifting Hook: An A-Frame or lifting hook may be used inside the laboratory
during assembly phase. When a lifting hook is used, the hook capacity must be certified
to hold the required weight of the magnet before installation!
Figure4.1: A-Frame Gantry for Lifting the Magnet Inside the Magnet Room
