Bruker AVANCE NEO User Manual

Magnet Access and Rigging
30 / 120 H157654_9_011
Crate Size (m) Magnet Transport Dimensions (m)
(for transport to the magnet room)
Magnet Type
(MHz/mm)
L W H Width Un-
crated
Height Un-
crated w/o
Pallet Jack*
Height Un-
crated with
Pallet
Jack**
300/89 Ascend 1.14 0.93 1.99 0.80 1.60 1.71
400/89 Ascend 1.14 0.93 1.99 0.80 1.60 1.71
500/89 Ascend 1.14 0.93 1.99 0.80 1.60 1.71
600/89 Ascend 1.14 1.36 2.06 0.95 1.74 1.85
700/89 Ascend 1.51 1.29 2.18 1.10 1.88 1.99
* Measured from magnet bottom plate to helium tower - this is the absolute minimum
height!
** The heights listed with pallet jack assume that the floor is level, thus the magnet
needs only to be jacked up approx. 2 cm for transport. If the floor is uneven, the magnet
may need to be jacked up with a pallet jack, which could add as much as 9 cm to the
transport height.
Table4.2: Door Dimensions: Wide Bore 89 mm
Crate Size (m) Magnet Transport Dimensions (m)
(for transport to the magnet room)
Magnet Type
(MHz/mm)
L W H Width Un-
crated
Height Un-
crated w/o
Pallet Jack*
Height Un-
crated with
Pallet
Jack**
200/154 Ascend 1.14 0.93 1.99 0.88 1.60 1.71
300/154 Ascend 1.14 0.93 1.99 0.88 1.60 1.71
* Measured from magnet bottom plate to helium tower - this is the absolute minimum
height!
** The heights listed with pallet jack assume that the floor is level, thus the magnet
needs only to be jacked up approx. 2 cm for transport. If the floor is uneven, the magnet
may need to be jacked up with a pallet jack, which could add as much as 9 cm to the
transport height.
Table4.3: Door Dimensions: Super Wide Bore 154 mm
