Transport,PackagingandStorage
Z33081_00_001 31
5 Transport,Packagingand
Storage
5.1 Packaging
AboutPackaging
Theindividualpackagesarepackagedinaccordancewithanticipatedtransportconditions.
Onlyenvironmentallyfriendlymaterialshavebeenusedinthepackaging.
The packaging is intended to protect the individual components from transport damage,
corrosion and other damage prior to assembly. Therefore do not destroy the packaging
andonlyremoveitshortlybeforeassembly.
HandlingPackagingMaterials
Dispose of packaging material in accordance with the relevant applicable legal
requirementsandlocalregulations.
5.2 SymbolsonthePackaging
Thefollowingsymbolsareaffixedtothepackagingmaterial.Alwaysobservethesymbols
duringtransportandhandling.
Top Thearrowtipsonthesignmarkthetopofthe
package.Theymustalwayspointupwards;
otherwisethecontentmaybedamaged.
Fragile Markspackageswithfragileorsensitive
contents.
Handlethepackagewithcare;donotallowthe
packagetofallanddonotallowittobe
impacted.
ProtectAgainstMoisture Protectpackagesagainstmoistureandkeep
dry.
AttachHere Liftinggear(liftingchain,liftingstrap)must
onlybeattachedtopointsbearingthissymbol.
CenterofGravity Marksthecenterofgravityofpackages.
Notethelocationofthecenterofgravitywhen
liftingandtransporting.
