Bruker BPHG 90 - Operating Conditions; Rating Plate

TechnicalData
28 Z33081_00_001
4.3 OperatingConditions
Environment
Data Value Unit
Temperaturerange 1532 °C
Relativehumidity 1090%noncondensing %
Operatingaltitude <=2000 m
Table4.5:OperatingEnvironment
CoolingDownProcess
Data Value Unit
Conversiontemperature 36to40 K
Cooldowntime <1fromroomtemperature h
Table4.6:CoolingDown
WarmUpProcess
Data Value Unit
Targettemperature 300 K
Warmuptime <20 min
Table4.7:WarmUp
4.4 RatingPlate
Figure4.1:RatingPlateExample
Theratingplateislocatedatthepowerinputandincludesthefollowinginformation:
Example
• Manufacturer:BrukerBiospinFrance
• RatedVoltage:200240
• Frequency50/60Hz
• Wires:2
• Ratedpower:500VA
