Maintenance
Continued from page before
Interval Device Work By
17.520 hours
(2 years)
Cryogenic
Refrigerator
• Replace the rotary valve. Refer to
chapter ”Replacement of the
Rotary Valve and the Cold
Head” on page 7-118.
• Replace the adsorber of the com-
pressor. Refer to the supplied
manual of the cryogenic refrigera-
tor.
• Check the values at the high and
low pressure gauges on the front
panel of the compressor if the
mean values are different and if
an oscillation of the needles is
noticeable. Refer to the supplied
manual of the cryogenic refrigera-
tor.
- Pressure to high: Vent helium
gas. Use the Service Kit.
- Pressure to low: Refill helium
gas of high purity (He 5.0,
99.999%). Use the Service Kit.
Bruker Service
35.040 hours
(4 years)
Cryogenic
Refrigerator
• Replace rotary valve and cold
head. Refer to chapter
”Replacement of the Rotary
Valve and the Cold Head” on
page 7-118.
• Replace the compressor.
• Pump and flush the flex lines with
helium gas of high purity (He 5.0,
99.999%)
Bruker Service
Table 7.2: Maintenance Timetable - part 2
