Bruker RS - Checking and Fitting the Drop-Off Plate

49
ZTKS0156 / Z31820 / Rev.: 03
Assembling
4.3.1.6 Checking and Fitting the Drop-off Plate
Figure 4.26: Checking and fitting the Drop-off Plate
1. Open the drop-off plate.
2. Clean the flange of the RT vessel and the
O-ring with ethanol.
3. Grease the O-ring with vacuum grease.
4. Close the drop-off plate.
5. Check the drop-off plate is correct
assembled.
