Maintenance
7.4 Maintenance Work at the Cryogenic Refrigerator
Approved Persons: Bruker Service only
7.4.1 Service Kit
For work at the Cryogenic Refrigerator use the Service Kit (Material No. Z119869).
Figure 7.1: Service Kit
The Service Kit includes:
• Non-ferromagnetic wrench set
• Aeroquip® adapters
• Helium Manifold
• Flex Line for servicing
• Frequently needed spare parts
Figure 7.2: Tool Tray
Optionally: Tool tray
The Tool Tray fits on each of the RS towers. It is
recommended for depositing tools and parts
necessary for work on top of the cryostat to avoid
falling objects.
