Safety
2.7 Safety Devices
The cryostat of the supplied magnet system is equipped with the following safety
devices:
Figure 2.1: Safety Devices of the RS Cryostat
1. Quench Valves
2. One-way Valve of the helium
vessel
3. Pressure Relief Valve of the
cold head turret
4. Drop-off Plate
