1.6 General View
Figure 1.1: General view RS Cryostat of the Magnet System
1. Cryogenic Refrigerator Compressor
(noise protection cover optionally)
2. Cryogenic Refrigerator Flex Lines
3. Rotary Valve (RV) covered by the
Rotary Valve Column (RVC)
4. Connection Line
5. Helium flow system
6. Current lead turret
7. Cryogenic Refrigerator Cold Head
8. Helium fill-in turret with helium fill-in
port
9. RT bore
10. RT vessel
11. Magnet Stand
