Transportation
3.4 Transportation by Fork Lift / Pallet Jack
Recommended for transporting the boxes to the installation site.
Approved Persons: Approved forklift / pallet jack operator
Precondition: The fork lift / pallet jack must be approved for the transportation weight
(see chapter Appendix, Technical Data).
Transport
Figure 3.2: Transportation by forklift
1. Check the route of transport for the minimal
height and width.
2. Check sufficient floor capacity on the route
of transport. In case of doubt ask a stress
analyst.
3. Check sufficient carrying capacity while
using an elevator.
4. Position the forks between the bars of the
box as shown in the figure. Make sure the
side towards the operator is the one with the
labels on it.
5. Make sure the forks of the fork lift are longer
than the box and projects out of the back of
the box as shown in the figure below.
6. Now lift the fork and move the box to the
site.
