BTL-5000 SERIES
USER'S MANUAL
page 47 of 56
Laser probes with infrared (invisible) radiation:
Type: BTL-448-05IC BTL-448-10IC BTL-448-20IC BTL-448-30IC
Output power:
50 mW ± 20 % 100 mW ± 20 % 200 mW ± 20 % 300 mW ± 20 %
Wavelength:
830 nm 830 nm 830 nm 830 nm
Class*:
3B 3B 3B 3B
Beam:
collimated collimated collimated collimated
Aperture:
Ø 4.4 mm Ø 4.4 mm Ø 4.4 mm Ø 4.4 mm
BNR:
0.015 rad ± 0.005 rad 0.015 rad ± 0.005 rad 0.015 rad ± 0.005 rad 0.015 rad ± 0.005 rad
NOHD**:
8.5 m 12.1 m 12.5 m 16.6 m
Type: BTL-448-40IC
Output power:
400 mW ± 20 %
Wavelength:
830 nm
Class*:
3B
Beam:
collimated
Aperture:
Ø 4.4 mm
BNR:
0.015 rad ± 0.005 rad
NOHD**:
19.2 m
*Laser class is classified according to IEC 60601-2-22:1995 and IEC 60825-1:1993/A2:2001.
**NOHD – nominal ocular hazard distance (nominal distance from the laser aperture in which the eye damage by
laser beam should not happen)
7.6 TECHNICAL PARAMETERS OF LASER CLUSTERS
Laser clusters with red (visible) radiation:
Type:
445-C25R02
Output power:
200 mW ± 20 % (4x 50 mW)
Wavelength:
4x 685 nm
Class*:
3B
Beam:
4x divergent
Aperture:
4x Ø 1.5 mm
Active area:
Ø 56 mm (25 cm
2
)
BNR:
4x 0.35 rad ± 0.05 rad
NOHD**:
0.2 m
Laser clusters with infrared (invisible) radiation:
Type:
445-C25I08 445-C25I16
Output power:
800 mW ± 20 % (4x 200 mW) 1600 mW ± 20 % (4x 400 mW)
Wavelength:
4x 830 nm 4x 830 nm
Class*:
3B 3B
Beam:
4x divergent 4x divergent
Aperture:
4x Ø 3.5 mm 4x Ø 3.5 mm
Active area:
Ø 56 mm (25 cm
2
) Ø 56 mm (25 cm
2
)
BNR:
4x 0.52 rad ± 0.17 rad 4x 0.52 rad ± 0.17 rad
NOHD**:
8.5 m 12.1 m
Combined laser clusters with red and infrared radiation:
Type:
445-C25RI10 445-C25RI18
Output power:
red: 200 mW ± 20 % (4x 50 mW)
infrared: 800 mW ± 20 % (4x 200 mW)
red: 200 mW ± 20 % (4x 50 mW)
infrared: 800 mW ± 20 % (4x 200 mW)
Wavelength:
red: 4x 685 nm
infrared: 4x 830 nm
red: 4x 685 nm
infrared: 4x 830 nm
Class*:
3B 3B
Beam:
8x divergent 8x divergent
Aperture:
red: 4x Ø 1.5 mm
infrared: 4x Ø 3.5 mm
red: 4x Ø 1.5 mm
infrared: 4x Ø 3.5 mm
