BTL-5000 SERIES
USER'S MANUAL
page 8 of 56
Tab. 2.1 Configuration of output connectors
Type
Output 1 Output 2 Output 3 Output 4 Output 5 Output 6
BTL-5110 Laser
L1A L1B Acup Door
BTL-5120 Laser
L1A L2A L1B L2B Acup Door
BTL-561x / 5621 Puls*
E1
BTL-5620 / 5625 Puls*
E1 E2
BTL-563x Puls*
E2 E1 E3
BTL-5640 Puls*
E1A, E1B E2A, E2B
BTL-5660 Puls*
E2A, E2B E1A, E1B E3A, E3B
BTL-5710 Sono
U1A U1B E input E output
BTL-5720 Sono
U1A U2A U1B U2B E input E output
BTL-5800 SL Combi
U1A L1A U1B L1B Acup Door
BTL-581x / 5621 S Combi*
U1A U1B E1
BTL-581x / 5621 S2 Combi*
U1A U2A U1B U2B E1
BTL-581x / 5621 SL Combi
U1A L1A U1B L1B E1 Door
BTL-581x / 5621 L Combi
L1A L1B E1 Door
BTL-581x / 5621 LL Combi
L1A L2A L1B L2B Door E1
BTL-5820 / 5625 S Combi*
U1A U1B E1 E2
BTL-5820 / 5625 SL Combi
U1A L1 U1B Door E1 E2
BTL-5820 / 5625 L Combi
L1A Door E1 E2
BTL-583x L Combi
L1A E2 Door E1 E3
BTL-5840 S Combi*
U1A U1B E1A, E1B E2A, E2B
BTL-5840 SL Combi
U1A L1 U1B Door E1A, E1B E2A, E2B
BTL-5840 L Combi
L1A Door E1A, E1B E2A, E2B
BTL-5860 L Combi
L1A E2A, E2B Door E1A, E1B E3A, E3B
* can be supplied or upgraded with HVT module
Notes:
E1 connector for connection of electrotherapy accessories (BTL-236-1, BTL vac) to E1 generator
E2 connector for connection of electrotherapy accessories (BTL-236-1, BTL vac) to E2 generator
E3 connector for connection of electrotherapy accessories (BTL-236-1, BTL vac) to E2 generator
E1A, E1B connector for connection of electrotherapy accessories (BTL-236-2, BTL vac) to E1 generator
E2A, E2B connector for connection of electrotherapy accessories (BTL-236-2, BTL vac) to E2 generator
E3A, E3B connector for connection of electrotherapy accessories (BTL-236-2, BTL vac) to E3 generator
E input connector for electrotherapy input BTL-56xx Puls on the ultrasound for combined therapy
E output connector for electrotherapy output BTL-56xx Puls on the ultrasound for combined therapy
L1A connector for connection of laser probe/cluster BTL-448/BTL-445 (e.g. red) to L1 generator
L1B connector for connection of laser probe/cluster BTL-448/BTL-445 (e.g. infrared) to L1 generator
L2A connector for connection of laser probe/cluster BTL-448/BTL-445 (e.g. red) to L2 generator
L2B connector for connection of laser probe/cluster BTL-448/BTL-445 (e.g. infrared) to L2 generator
L1 connector for connection of laser probe/cluster BTL-448/BTL-445 to L1 generator
U1A connector for connection of ultrasound head BTL-237 (e.g. 1 cm
2
) to U1 generator
U1B connector for connection of ultrasound head BTL-237 (e.g. 4 cm
2
) to U1 generator
U2A connector for connection of ultrasound head BTL-237 (e.g. 1 cm
2
) to U2 generator
U2B connector for connection of ultrasound head BTL-237 (e.g. 4 cm
2
) to U2 generator
Door connector for sensor of open door
Acup connector for acupuncture electrode
How many patients and to which outputs you can simultaneously connect can be seen on the display after pressing
the menu button in menu / accessories / connectors - information.
