Buhler SnackFix - Lubrication list

Lubricate the machine
Maintenance Plan
86 SnackFix  2016-08
No.
Fig.
Designation, ma-
nufacturer, type
Qty.
Lubricant
Amount *)
Activity, lubrication,
change interval
  Fig. 31
EGW 180-100:
gear motor
(SEW, KAZ37)
1
Oil:
CLP HC 460 NSF
H1
1.0 l / 0.55 l
(0.26 gal /
0.15 gal)
Oil, check oil-level,
every 3000 h
Oil change, every 3
years at the latest
  Fig. 32
TB 100: gear
motor (SEW,
KA37)
1
Oil:
CLP HC 220 NSF
H1
0.50 l / 0.25 l
(0.13 gal /
0.07 gal)
Oil, check oil-level,
every 3000 h
Oil change, every 3
years at the latest
  Fehler!
Verweis-
quelle
konnte
nicht ge-
funden
werden.
EGW 180-100:
gear motor
(SEW, KAZ37)
1
Oil:
CLP HC 460 NSF
H1
1.0 l / 0.55 l
(0.26 gal /
0.15 gal)
Oil, check oil-level,
every 3000 h
Oil change, every 3
years at the latest
  Fehler!
Verweis-
quelle
konnte
nicht ge-
funden
werden.
TB 100 (SZ):
gear motor
(SEW, KA37)
1
Oil:
CLP HC 460 NSF
H1
0.50 l
(0.13 gal)
Oil, check oil-level,
every 3000 h
Oil change, every 3
years at the latest
  Fig. 33
QS 120 M/TB:
guiding of plung-
er
1
Grease:
Klüber PARALIQ GA
343
Thin grease
film
After cleaning, if
required
  Fig. 33
QS 120 M/TB:
guiding of knife
carriage
4
Grease:
Klüber PARALIQ GA
343
Thin grease
film
After cleaning, if
required
  Fig. 34
QS 120 M/TB:
guiding of follow
carriage
2
Grease:
Klüber PARALIQ GA
343
Thin grease
film
After cleaning, if
required
  Fehler!
Verweis-
quelle
QS 120 M/TB:
container of part-
ing liquid
1
Food-approved part-
ing liquid:
e.g. alcohol, sugar
200 ml
(0.05 gal)
Fill up, if required
