28
Type 8692, 8693
english
Description of System
7.2 Factory settings of the positioner
Function Factory setting Function Factory setting
ACTUATOR SINGLE or DOUBLE*
INPUT 4-20 mA
CHARACT linear
DIR.CMD Rise
CUTOFF Min 0 %
Max 100 %
DIR.ACT Rise
SPLTRNG Min 0 %
Max 100 %
X.LIMIT Min 0 %
Max 100 %
X.TIME
Open (1s) Values of X.TUNE determined
Close (1s) Values of X.TUNE determined
After executing of SET.FACTORY: 1s
OUTPUT
OUT ANALOG Out POS
OUT type 4-20 mA
OUT BIN1 Out DEV.X
Lim. DEV.X 1.0 %
OUT.BIN1 type normally opened
OUT BIN2 Out DEV.X
Lim. DEV.X 1.0 %
OUT.BIN1 type normally opened
BINARY. IN SafePos
BIN. IN type normally opened
X.CONTROL
DBND 1.0 %
KXopn (1) Values of X.TUNE determined
KXcls (1) Values of X.TUNE determined
After executing of SET.FACTORY: 1
SECURITY
Access Code 1 0000
SAFEPOS 0 %
SIG.ERROR
SP/CMD Input Error off
P.CONTROL
PARAMETER
DBND 1.0 %
KP 1.00
TN 999.9
TV 0.0
X0 0.0 %
FILTER 0
SETUP
SP-INPUT intern
PV-INPUT 4-20 mA
PV-SCALE PVmin 0.0
PV-SCALE PVmax 100.0
P.CO-INIT standard
* preset at the factory according to the actuator
