1502154 Rev D Reference Tables D-7
Table D.1 SEQ-1G Series Cable Equalizers
P/N Insertion Loss in dB at Frequency (MHz)
54 85 105 222 550 750 870 1002 *
SEQ-1G-00 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
SEQ-1G-02 2.0 1.9 1.8 1.5 1.2 0.8 0.7 0.7 1.55
SEQ-1G-03 2.9 2.8 2.6 2.3 1.7 1.1 0.9 0.8 2.8
SEQ-1G-04 4.0 3.8 3.6 3.1 2.1 1.6 1.4 1.0 3.7
SEQ-1G-05 5.0 4.7 4.6 3.8 2.4 1.7 1.4 1.0 5.1
SEQ-1G-06 6.0 5.7 5.5 4.6 2.8 2.0 1.6 1.0 6.35
SEQ-1G-07 7.0 6.6 6.4 5.4 3.1 2.0 1.6 1.0 7.75
SEQ-1G-08 8.0 7.4 7.1 5.8 3.4 2.2 1.6 1.0 8.9
SEQ-1G-09 9.0 8.5 8.2 6.8 3.8 2.5 1.9 1.0 10.2
SEQ-1G-10 10.0 9.3 9.0 7.3 4.0 2.5 1.9 1.0 11.45
SEQ-1G-11 11.0 10.4 10.0 8.1 4.5 2.9 2.1 1.0 12.7
SEQ-1G-12 12.0 11.1 10.8 8.8 4.9 3.0 2.1 1.0 14.0
SEQ-1G-13 13.0 12.2 11.8 9.5 5.1 3.2 2.2 1.0 15.25
SEQ-1G-14 14.0 13.0 12.4 10.2 5.7 3.5 2.3 1.0 16.5
SEQ-1G-15 14.9 13.9 13.3 10.8 5.8 3.5 2.3 1.0 17.8
SEQ-1G-16 16.0 14.9 14.3 11.5 6.3 3.7 2.4 1.0 19.05
SEQ-1G-17 17.0 15.6 15.0 12.2 6.5 3.9 2.4 1.0 20.3
SEQ-1G-18 18.0 16.9 16.2 13.2 7.0 4.0 2.4 0.8 21.8
SEQ-1G-19 19.0 17.7 16.9 13.7 7.3 4.1 2.4 0.8 23.05
SEQ-1G-20 20.0 18.5 17.7 14.2 7.6 4.4 2.6 0.8 24.05
*dB of cable equalized at 1002MHz
Specification 1500769 Rev C
Return Loss I/O: 18 dB, min. SEQ-1G-02 through 18 16dB, min. SEQ-1G-19 and 20
Passband Flatness: ±0.3dB SEQ-1G-02 through 18 ±0.4dB SEQ-1G-19 and 20
Table D.2 SCS-1G Series Cable Simulators
P/N Insertion Loss in dB at Frequency (MHz) dB of cable simulated at
50 70 80 550 750 806 862 1002 350 450 550 650 750 806 862 1002
SCS-1G-02 1.0 1.0 1.1 1.6 1.8 1.9 1.9 2.0 0.7 0.8 0.9 1.0 1.1 1.1 1.2 1.3
SCS-1G-03 1.0 1.1 1.1 2.3 2.6 2.7 2.8 3.0 1.4 1.6 1.8 2.0 2.2 2.2 2.3 2.5
SCS-1G-04 1.0 1.1 1.2 2.9 3.4 3.6 3.7 4.0 2.1 2.4 2.7 3.0 3.2 3.3 3.5 3.8
SCS-1G-05 1.0 1.2 1.3 3.6 4.3 4.4 4.6 5.0 2.8 3.2 3.6 3.9 4.3 4.5 4.6 5.0
SCS-1G-06 1.0 1.2 1.3 4.2 5.1 5.3 5.5 6.0 3.5 4.0 4.5 4.9 5.3 5.6 5.8 6.3
SCS-1G-07 1.0 1.3 1.4 4.9 5.9 6.2 6.4 7.0 4.2 4.8 5.4 5.9 6.4 6.7 6.9 7.5
SCS-1G-08 1.0 1.3 1.5 5.5 6.7 7.0 7.3 8.0 4.9 5.6 6.3 6.9 7.5 7.8 8.1 8.8
SCS-1G-09 1.0 1.4 1.5 6.1 7.5 7.9 8.2 9.0 5.6 6.4 7.2 7.9 8.6 8.9 9.2 10.0
SCS-1G-10 1.0 1.4 1.6 6.8 8.3 8.7 9.1 10.0 6.3 7.2 8.1 8.9 9.6 10.0 10.4 11.3
SCS-1G-11 1.0 1.5 1.7 7.4 9.2 9.6 10.0 11.0 7.0 8.0 9.0 9.9 10.7 11.1 11.5 12.5
SCS-1G-12 1.0 1.5 1.7 8.1 10.0 10.5 10.9 12.0 7.7 8.8 9.9 10.8 11.8 12.2 12.7 13.8
SCS-1G-13 1.0 1.6 1.8 8.7 10.8 11.3 11.8 13.0 8.4 9.6 10.8 11.8 12.8 13.4 13.9 15.0
SCS-1G-14 1.0 1.6 1.9 9.4 11.6 12.2 12.7 14.0 9.1 10.4 11.6 12.8 13.9 14.5 15.0 16.3
SCS-1G-15 1.0 1.7 2.0 10.0 12.4 13.0 13.6 15.0 9.8 11.2 12.5 13.8 15.0 15.6 16.2 17.5
Passband Flatness: ±0.4dB Specification 1500883 Rev A
Return Loss I/O: 16/16dB (-02 thru -12)
Return Loss I/O: 15/15dB (-13 thru -15)
