D
D-8 Flex Max901e 1GHz Trunk and Bridger Amplifiers 1502154 Rev D
Table D.3 GEQL-1GHz Series Linear Equalizers
Model Number
Insertion Loss in dB at Frequency in MHz
45 70 80 90 100 300 400 500 600 700 800 900 1000
GEQL-1GHz-000 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
GEQL-1GHz-020 2.0 2.0 2.0 2.0 1.9 1.7 1.6 1.5 1.4 1.3 1.2 1.1 1.0
GEQL-1GHz-030 3.0 2.9 2.9 2.9 2.9 2.5 2.3 2.0 1.8 1.6 1.4 1.2 1.0
GEQL-1GHz-040 4.0 3.9 3.9 3.9 3.8 3.2 2.9 2.6 2.3 2.0 1.6 1.3 1.0
GEQL-1GHz-050 5.0 4.9 4.9 4.8 4.8 3.9 3.5 3.1 2.7 2.3 1.8 1.4 1.0
GEQL-1GHz-060 6.0 5.9 5.8 5.8 5.7 4.7 4.1 3.6 3.1 2.6 2.0 1.5 1.0
GEQL-1GHz-070 7.0 6.8 6.8 6.7 6.7 5.4 4.8 4.1 3.5 2.9 2.3 1.6 1.0
GEQL-1GHz-080 8.0 7.8 7.7 7.7 7.6 6.1 5.4 4.7 3.9 3.2 2.5 1.7 1.0
GEQL-1GHz-090 9.0 8.8 8.7 8.6 8.5 6.9 6.0 5.2 4.4 3.5 2.7 1.8 1.0
GEQL-1GHz-100 10.0 9.8 9.7 9.6 9.5 7.6 6.7 5.7 4.8 3.8 2.9 1.9 1.0
GEQL-1GHz-110 11.0 10.7 10.6 10.5 10.4 8.3 7.3 6.2 5.2 4.1 3.1 2.0 1.0
GEQL-1GHz-120 12.0 11.7 11.6 11.5 11.4 9.1 7.9 6.8 5.6 4.5 3.3 2.2 1.0
GEQL-1GHz-130 13.0 12.8 12.7 12.5 12.4 9.9 8.6 7.3 6.1 4.8 3.5 2.3 1.0
Impedance: 75 ohm Molded red plastic 3-pin plug-in Specification 1500202 Rev C
Return Loss I/O: 18dB min.
Flatness: ±0.3dB; GEQL-1GHz-000: ±0.15dB (Flatness measured with respect to slope)
Insertion loss for other frequencies can be determined on a linear tilt basis
Table D.4 GEQC-1GHz Cable Equalizer
Insertion Loss in dB at Frequency in MHz
Model Number 45 54 70 80 222 400 500 600 700 800 870 1000
GEQC-1GHz-050 4.7 4.6 4.5 4.4 3.5 2.7 2.3 2.0 1.7 1.4 1.2 0.7
GEQC-1GHz-070 6.4 6.2 6.0 5.9 4.6 3.5 3.0 2.5 2.0 1.6 1.4 0.7
GEQC-1GHz-090 7.8 7.6 7.5 7.3 5.7 4.2 3.5 2.8 2.1 1.6 1.3 0.8
dB per 100 feet is 1.87416 Molded brown plastic 3-pin plug-in Specification 1502429 Rev B
Impedance: 75 ohm
Return Loss I/O: 22 dB min.
Flatness: ± 0.3 dB.
Bandwidth: 45-1000MHz
Definition of cable signature: (S-Parameter file cable loss) X (Fiber T-10.625” from equation)
Table D.5 GEQC-870-080 Cable Equalizer
Insertion Loss in dB at Frequency in MHz
Model Number 45 54 70 80 222 400 500 600 700 800 870
GEQC-870-080 6.9 6.8 6.6 6.5 4.9 3.5 2.9 2.2 1.5 1.0 0.7
dB per 100 feet is 1.87416 Molded blue plastic 3-pin plug-in Specification 1501842 Rev B
Impedance: 75 ohm
Return Loss I/O: 22 dB min.
Flatness: ± 0.3 dB.
Bandwidth: 45-870MHz
Definition of cable signature: S-Parameter file cable loss “Times Fiber T-10 .625” from equation)
