1502154 Rev D Reference Tables D-9
Table D.6 SEQ-862 Series Cable Equalizers
1
1. Only SEQ-862 equalizers without covers can be used with Flex Max 901 trunk and bridger amplifiers.
Model P/N Insertion Loss in dB at Frequency (MHz)
54 70 80 500 600 700 800 862 *
SEQ-0 162290-00 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
SEQ-862-02 162240-25 1.9 1.9 1.9 1.4 1.3 1.2 1.1 1.0 1.0
SEQ-862-03 162240-15 2.9 2.8 2.8 1.6 1.5 1.4 1.2 1.0 2.0
SEQ-862-04 162240-08 4.0 4.0 4.0 1.9 1.6 1.4 1.2 1.0 4.0
SEQ-862-05 162240-16 4.8 4.6 4.5 2.1 1.7 1.4 1.2 1.0 5.0
SEQ-862-06 162240-17 5.9 5.6 5.6 2.6 2.1 1.6 1.2 1.0 6.5
SEQ-862-07 162240-18 6.9 6.6 6.6 3.1 2.5 1.9 1.4 1.0 7.8
SEQ-862-08 162240-10 7.8 7.5 7.4 3.4 2.7 2.1 1.4 1.0 8.7
SEQ-862-09 162240-19 8.8 8.4 8.3 3.6 2.8 2.0 1.4 1.0 10.5
SEQ-862-10 162240-20 9.6 9.1 8.9 3.8 2.9 2.1 1.4 1.0 11.0
SEQ-862-11 162240-21 10.8 10.3 10.2 4.4 3.5 2.5 1.6 1.0 13.0
SEQ-862-12 162240-11 11.6 11.1 10.8 4.7 3.7 2.7 1.7 1.0 14.5
SEQ-862-13 162240-22 12.8 12.4 12.0 5.0 3.9 2.8 1.7 1.0 15.5
SEQ-862-14 162240-23 13.6 12.9 12.7 5.2 4.0 2.9 1.8 1.0 16.5
SEQ-862-15 162240-24 14.5 13.9 13.5 5.6 4.2 3.0 1.8 1.0 17.5
SEQ-862-16 162240-12 15.3 14.7 14.3 6.1 4.7 3.3 2.0 1.0 19.0
SEQ-862-17 162240-28 17.5 16.8 16.4 6.5 5.1 3.5 2.0 1.0 21.3
SEQ-862-18 162240-29 18.4 17.5 17.2 6.8 5.2 3.6 2.0 1.0 22.4
SEQ-862-19 162240-30 19.5 18.6 18.2 7.2 5.7 3.8 2.0 1.0 23.9
SEQ-862-20 162240-31 20.3 19.4 19.0 7.6 5.8 3.9 2.0 1.0 24.9
Passband Flatness: ±0.3dB *dB of cable equalized at highest frequency
Return Loss I/O: 20/18dB, min. Specification 600438 Rev J
Table D.7 SCS-862 Series Cable Simulators
Model P/N Insertion Loss in dB at Frequency (MHz) dB of cable simulated at
54 70 80 550 750 806 862 450 550 750 806 862
SCS-862-02 162451-02 1.0 1.0 1.0 1.7 1.9 2.0 2.0 0.8 1.0 1.2 1.2 1.3
SCS-862-03 162451-03 1.0 1.0 1.0 2.4 2.8 2.9 3.0 1.7 1.9 2.3 2.5 2.6
SCS-862-04 162451-04 1.0 1.1 1.2 3.2 3.8 3.9 4.0 2.6 2.9 3.5 3.8 3.9
SCS-862-05 162451-05 1.0 1.0 1.1 3.9 4.7 4.9 5.0 3.4 3.9 4.7 5.0 5.2
SCS-862-06 162451-06 1.0 1.0 1.2 4.6 5.5 5.8 6.0 4.2 4.8 5.7 6.2 6.4
SCS-862-07 162451-07 1.0 1.2 1.4 5.2 6.3 6.6 7.0 5.4 6.0 7.1 7.4 7.7
SCS-862-08 162451-08 1.0 1.3 1.4 6.0 7.3 7.6 8.0 6.2 6.9 8.2 8.6 8.9
SCS-862-09 162451-09 1.0 1.3 1.6 6.6 8.1 8.5 9.0 7.1 7.9 9.4 9.8 10.2
SCS-862-10 162451-10 1.0 1.4 1.6 7.3 9.0 9.4 10.0 8.0 8.9 10.6 11.1 11.5
SCS-862-11 162451-11 1.0 1.5 1.7 8.0 10.0 10.3 11.0 8.9 9.9 11.8 12.3 12.8
SCS-862-12 162451-12 1.0 1.5 1.7 8.7 10.9 11.4 12.0 9.8 11.0 13.1 13.6 14.1
SCS-862-13 162451-13 1.0 1.5 1.8 9.5 11.9 12.4 13.0 10.7 12.0 14.3 14.8 15.4
SCS-862-14 162451-14 1.0 1.6 1.9 10.0 12.9 13.4 14.0 11.5 12.9 15.4 16.0 16.6
SCS-862-15 162451-15 1.0 1.7 2.0 10.6 13.7 14.3 15.0 12.4 13.9 16.6 17.3 17.9
Passband Flatness: 0.4dB P-V (-2 through -13); 0.6dB P-V (-14 and -15) Specification: 600662 Revision B
Return Loss I/O: 18/16dB (-2 through -13); 16/16dB (-14 and -15)
