Table D.8 SEQ-750 Series Cable Equalizers
1
1. Only SEQ-750 equalizers without covers can be used with Flex Max 901 trunk and bridger amplifiers.
Model Number
dB of
cable
equalized
at highest
frequency
Insertion Loss in dB at Frequency (MHz)
P/N 54 70 80 222 350 450 550 650 750
SEQ-0 162290-00 00 00 00 00 00 00 00 00 0.0 00
SEQ-750-02 162290-02 2.02.02.01.81.41.31.31.21.0 1.5
SEQ-750-03 162389-03 3.02.82.72.41.91.71.51.31.0 2.5
SEQ-750-04 162389-04 3.93.93.83.12.42.01.71.41.0 4.0
SEQ-750-05 162389-05 4.94.64.53.52.92.31.81.41.0 5.0
SEQ-750-06 162389-06 5.95.75.64.23.32.72.01.51.0 6.5
SEQ-750-07 162389-07 7.06.86.65.03.62.82.01.61.0 8.0
SEQ-750-08 162389-08 8.07.97.65.54.23.32.51.81.0 9.0
SEQ-750-09 162389-09 9.08.88.66.34.83.82.72.01.0 10.5
SEQ-750-10 16238910 9.89.49.26.75.03.82.82.01.0 12.0
SEQ-750-11 162389-11 11.0 10.5 10.2 7.5 5.5 4.2 3.0 2.0 1.0 13.5
SEQ-750-12 162389-12 11.8 11.3 11.0 8.1 6.0 4.6 3.3 2.2 1.0 14.5
SEQ-750-13 162389-13 12.9 12.4 12.2 8.9 6.6 5.1 3.7 2.5 1.0 16.0
SEQ-750-14 162389-14 14.0 13.5 13.2 9.7 6.9 5.3 3.8 2.5 1.0 17.0
SEQ-750-15 162389-15 14.9 14.3 13.9 10.1 7.5 5.8 4.3 2.6 1.0 18.5
SEQ-750-16 162389-16 15.8 14.9 14.5 10.5 8.0 6.1 4.4 2.7 1.0 20.0
SEQ-750-17 162389-17 16.8 16.0 15.6 11.3 8.2 6.2 4.4 2.6 1.0 21.0
SEQ-750-18 162389-18 17.9 17.1 16.6 11.9 8.6 6.6 4.6 2.6 1.0 22.4
SEQ-750-19 162389-19 18.8 17.8 17.4 12.3 9.1 6.9 4.8 2.7 1.0 23.7
SEQ-750-20 162389-20 19.8 19.0 18.5 13.2 9.5 7.2 5.0 2.8 1.0 25.0
SEQ-750-21 162389-21 20.8 19.8 19.3 13.4 10.0 7.5 5.2 2.9 1.0 26.3
SEQ-750-2-2 162433-02 2.82.82.82.52.32.22.12.12.0 1.1
SEQ-750-4-2 162469-02 4.54.44.33.63.12.82.52.22.0 3.3
SEQ-750-4-3 162469-03 5.55.45.34.74.13.83.53.23.0 3.3
SEQ-750-5-5 162469-05 8.98.68.67.66.96.35.85.45.0 5.0
Passband Flatness: ±0.3 dB Document number: 600563 Revision J
Return Loss I/O: 18/16 dB
