1502154 Rev D Reference Tables D-11
Table D.9 SCS-750 Series Cable Simulators
Model
Number
P/N Insertion Loss in dB at Frequency (MHz) dB of cable simulated at
54 70 80 222 350 450 550 650 750 350 450 550 650 750
SCS-750-02 162391-02 1.01.01.01.31.51.61.71.81.80.70.80.91.01.1
SCS-750-03 162391-03 1.01.01.01.62.02.22.42.62.81.51.71.92.12.3
SCS-750-04 162391-04 1.01.01.11.92.42.73.03.33.52.22.52.83.03.3
SCS-750-05 162391-05 1.01.11.22.33.03.43.94.34.63.23.64.04.44.8
SCS-750-06 162391-06 1.01.11.33.13.94.55.15.76.24.65.25.86.47.0
SCS-750-07 162391-07 1.01.11.33.34.24.95.66.26.85.05.76.47.07.6
SCS-750-08 162391-08 1.01.11.53.44.75.66.37.17.85.96.77.58.29.0
SCS-750-09 162391-09 1.0 1.2 1.5 4.0 5.4 6.4 7.3 8.2 9.0 6.9 7.9 8.8 9.7 10.5
SCS-750-10 162391-10 1.0 1.2 1.5 4.1 5.7 6.7 7.7 8.7 9.5 7.4 8.4 9.4 10.4 11.2
SCS-750-11 162391-11 1.0 1.2 1.5 4.3 6.4 7.6 8.7 9.8 10.7 8.4 9.6 10.7 11.9 12.8
SCS-750-12 162391-12 1.1 1.6 2.0 5.1 7.0 8.3 9.5 10.7 11.8 9.4 10.7 11.9 13.2 14.2
SCS-750-13 162391-13 1.1 1.6 2.0 5.4 7.5 8.9 10.2 11.6 12.7 10.1 11.6 12.9 14.3 15.4
SCS-750-14 162391-14 1.1 1.6 1.7 5.7 8.2 9.8 11.3 12.8 14.1 11.3 12.9 14.4 15.9 17.2
SCS-750-15 162391-15 1.1 1.6 1.7 5.8 8.7 10.4 12.0 13.6 15.0 12.1 13.8 15.4 17.0 18.4
Passband Flatness: 0.6 dB, P-V Document number: 600647 Revision B
Return Loss I/O: 18/16 dB
Table D.10 MEQ-65 and MEQT-65 Series Cable Equalizers
Model Number
P/N
Insertion Loss in dB
at Frequency (MHz)
dB of cable equalized at
5 65 65 300 400 450 550 750
MEQ-65-02 333977-02 2.0 1.0 1.3 3.0 3.5 3.7 4.2 5.0
MEQ-65-03 333977-03 2.9 1.0 2.7 6.0 7.0 7.5 8.3 9.9
MEQ-65-04 333977-04 3.9 1.0 4.0 9.0 10.5 11.2 12.5 14.9
MEQ-65-05 333977-05 5.2 1.0 5.8 13.0 15.2 16.2 18.1 21.5
MEQ-65-06 333977-06 6.2 1.0 7.1 16.0 18.7 19.9 22.2 26.5
MEQ-65-07 333977-07 7.1 1.0 8.5 19.0 22.2 23.6 26.4 31.5
MEQT-65-02 333978-02 4.4 2.5 2.7 6.0 7.0 7.5 8.3 9.9
MEQT-65-03 333978-03 5.4 2.5 4.0 9.0 10.5 11.2 12.5 14.9
MEQT-65-04 333978-04 6.7 2.5 5.8 13.0 15.2 16.2 18.1 21.5
MEQT-65-05 333978-05 7.7 2.5 7.1 16.0 18.7 19.9 22.2 26.5
MEQT-65-06 333978-06 8.6 2.5 8.5 19.0 22.2 23.6 26.4 31.5
MEQT-65-07 333978-07 9.6 2.5 9.8 22.0 25.7 27.4 30.6 36.4
Passband
Flatness:
MEQ-65 (±0.1dB) MEQ-65 Document number: 600615 Revision B
MEQT-65 (±0.2dB) MEQT-65 Document number: 600616 Revision B
Return Loss I/O: 18/16dB
